The TP-LINK TL-WN350G 54M
Wireless PCI Adapter provides you the flexibility to install your PC in
the most convenient location available, without the cost of running
network cables.
The Adapter s auto-sensing capability allows high packet transfer rate
of up to 54Mbps for maximum throughput, or dynamic range shifting to
lower speeds due to distance or operating limitations in an environment
with a lot of electromagnetic interference. It can also interoperate
with all 11Mbps wireless (802.11b) products.
TL-WN350G supports up to 128-bit WEP and WPA encryption, so you need not
to worry about the safety of your wireless data or privacy.
TL-WN350G is also quite easy to install with the help of TP-LINK s
easy-to-configure wireless client utility. With TL-WN350G, you can
easily connect your PC to your Wireless Access Point and enjoy the
pleasure of Wi-Fi.
Features:
- Supports 64/128-bit WEP, complies
with 128 bit WPA standard(TKIP/AES), supports MIC, IV Expansion,
Shared Key Authentication, IEEE 802.1X
- Supports 54/48/36/24/18/12/9/6Mbps
or 11/5.5/2/1Mbps wireless LAN data transfer rates
- Supports Ad-Hoc and Infrastructure
modes
- Supports roaming between access
points when configured in Infrastructure mode
- Ease to configure and provides
monitoring information
- Supports Windows 98, ME, 2000, 2003,
XP, Vista, XP64
- Supports fixed antenna
Specifications:
|
Software Specification
|
|
Chipset |
Atheros |
|
Standards
|
IEEE 802.11g, IEEE 802.11b
|
|
Wireless Signal Rates With
Automatic Fallback
|
11g: 54/48/36/24/18/12/9/6 Mbps
(Dynamic)
11b: 11/5.5/3/2/1 Mbps (Dynamic)
|
|
Frequency Range
|
2.4-2.4835GHz
|
|
Wireless Transmit Power
|
18dBm(MAX)
|
|
Modulation Type
|
1M DBPSK, 2M DQPSK, 5.5M/11M CCK,
6M/9M/12M/18M/24M/36M/48M/54M OFDM
|
|
Receiver Sensitivity
|
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
256K: -105dBm@8% PER
|
|
Work Mode
|
Ad-Hoc
Infrastructure
|
|
Wireless Security
|
64/128 bit WEP
WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
|
|
Support Operating System
|
Windows 98SE/ME/2000/XP/Vista
|
|
Hardware Specification
|
|
Interface
|
32-bit PCI connector
|
|
Antenna Type
|
2dBi Fixed Omni-directional
Antenna
|
|
Certifications
|
CE, FCC
|
|
Operating Temperature
|
0 C~40 C (32 ~104 )
|
|
Storage Temperature
|
-40 C~70 C (-40 ~158 )
|
|
Relative Humidity
|
10% ~ 90%, non condensation
|
|
Storage Humidity
|
5%~95% non-condensing
|
|
Dimensions
|
5.2 4.8 0.9 in. (133 121 22 mm)
|
System Requirements
- 300 MHz processor or higher
- 64MB memory or greater
- 32-bit PCI slot
- Windows 98SE/ME/2000/2003/XP/Vista/7
Package Contents:
- One TP-LINK TL-WN350G 54M Wireless
PCI Adapter
- One Resource CD with Driver, User
Guide, and Configuration Utility
- Quick Installation Guide
Warranty: 1 year
|
